Model		DFM2-1000
Indication		Red segment LED 10X5.5(Height X Width)mm
Indication Range		0 to 99999 Max.5-digit indication
Calculation		Frequency measurement computation system
Decimal Point		Under decimal point 0 to 4-digit indication Arbitrary setting possible
Indication Value Calibration Method		Scaling is changed by the front panel key.
Indication Flow Rate Range		0.2 to 2/minA0.5 to 5/minA2.5 to 25/minA12 to 120/min
Setting of Auto-zero Time		Setting 1 to 9 seconds in 1 second unit is possible.
Pluse Input(INI)		Input Resistance : 10k(Pull-up to DC24V) Negative Logic Operation Input Current : 2mA or under Operation Voltage : ON Voltage = 2V or under OFF Voltage = 5V or above Pilse Width : 50s or above in both H and L
Setting inhibition input(KPT)		Input Resistance : 10k(Pull-up to DC24V) Negative Logic Operation Input Current : 2mA or under Operation Voltage : ON Voltage = 2V or under (Changeing each set value impossible) OFF voltage = 5V or above (Changing each set value possible)
Setting Memory		Memory System : Memorizing by non-volatile element(NV-RAM) Memory Time : about 10 years
Power Supply Voltage		AC100V/200VA90 to 120% 50/60Hz
Outer Supply Power		DC24V10% 80mA
Consumed Power		approx. 8.5AV
Ambient Temperature		-10 to +50 Celsius Degree(But do not use when frozen)
Ambient Humidity		35 to 85%RH (But do not condensing)
Stored Ambient Temperature		-25 to +85 Celsius Degree(But do not use when frozen)
Weight		approx. 450g(Including Accessories)
Adaptable Machine Type		Panel Fitting Bracket/Vis

Note)

As for changing of each setting, refer to the Instruction Manual attached to the commodity.
